Redefining precision through Metal Injection Molding. Our design protocols ensure geometric complexity with structural integrity at micron-level tolerances.
YEARS IN MIM
0+
EXPERT EMPLOYEES
0+
YEARLY SALES
0M (USD)
SINTERED DENSITY
>0%
Design Guidelines
Success in MIM starts at the CAD level. We optimize for material flow and thermal dynamics to eliminate porosity and maximize mechanical properties.
01
Material Flow
Optimization of gate placement to ensure uniform cavity filling and minimize thermal stresses during the debinding phase.
02
Thermal Dynamics
Controlled cooling rates and sintering profiles designed to manage linear shrinkage and prevent component warping.
03
Mass Balancing
Strategic wall thickness distribution to maintain isotropic properties across complex cross-sections.
TOOLING ARCHITECTURE
Parting Lines
Strategic placement for flash-free finishes and aesthetic integrity on visible surfaces.
Gating & Sprues
Sub-gates and hot-runner systems designed for zero-waste high-volume production.
Ejector Pins
Precision placement to avoid part deformation during the green-state extraction.
Core Guidelines
Complexity
Infinite Geometric Freedom
Transitions
Radiused Radii Preferred
Wall Thickness
0.5mm – 12mm Optimized
Tolerances
± 0.3% Precision Range
“Our engineering team provides full DFM Design for Manufacturing reports for every tooling project, ensuring 100% first-pass yield.”
Material Selection
Feedstock Properties: The mixture of metal powders and binder materials (feedstock) should have properties compatible with your design requirements, including flow characteristics and particle size distribution
